Magene EXAR Carbon Spoke For Ultra DB405

The Magene EXAR Carbon Spoke for Ultra DB405 is a replacement spoke designed specifically for the EXAR Ultra DB405 carbon wheelset. Made from HI-MOD carbon fiber, it combines low weight with high stiffness and tensile strength to help maintain the wheelset’s original performance characteristics. Each spoke weighs approximately 2.8 g, helping reduce rotational weight compared with traditional steel spokes. The spoke is available in different configurations for the front and rear wheels, including drive-side and non-drive-side positions. Its aerodynamic design conceals the metal hardware and creates a wider, thinner profile for reduced wind resistance. This replacement spoke is a practical choice for maintaining the structural integrity, responsiveness, and performance of a Magene EXAR Ultra DB405 wheelset.

Key Features

• Material: HI-MOD carbon fiber

• Weight: Approximately 2.8 g per spoke

• Compatibility: Magene EXAR Ultra DB405 carbon wheelset

• Strength: Designed to provide high tensile strength and stiffness

• Aerodynamic Design: Wider and thinner profile helps reduce wind resistance

• Replacement Type: Individual replacement spoke

• Position Options: Front drive-side, front non-drive-side, rear drive-side, and rear non-drive-side

• Lacing Support: Compatible with the DB405's 2:1 spoke lacing configuration

Product Specifications

• Product Type: Carbon replacement spoke

• Brand: Magene

• Model: EXAR Ultra DB405

• Spoke Material: HI-MOD Carbon Fiber

• Weight Per Spoke: 2.8 g

• Front Spoke Tension: 110 kgf ±10%

• Rear Drive-Side Tension: 130 kgf ±10%

• Rear Non-Drive-Side Tension: 110 kgf ±10%

• Front Lacing: 21H, 2:1 – brake side ×2, non-brake side radial

• Rear Lacing: 21H, 2:1 – drive side ×2, brake side radial

• Country of Origin: China

Carbon Spoke Performance

• Low Rotational Weight: At approximately 2.8 g per spoke, the carbon construction helps keep wheel weight low.

• High Stiffness: HI-MOD carbon fiber provides the rigidity needed for responsive wheel performance.

• Power Transfer: The lightweight, stiff construction helps maintain efficient transfer of pedaling force through the wheel.

• Aerodynamic Profile: The wider, thinner spoke shape is designed to minimize airflow disruption.

• Balanced Lacing: The DB405's 2:1 lacing arrangement helps distribute spoke tension effectively across the wheel.

Easy Operation / Usage

• Replacement: Use the spoke as a replacement for a damaged or worn spoke on a compatible EXAR Ultra DB405 wheelset.

• Position: Select the correct spoke version according to its front/rear and drive/non-drive-side position.

• Installation: Spoke replacement should be performed with appropriate wheel-building tools and correct spoke tension.

• Compatibility: Confirm the spoke position and wheel model before installation.

Why Choose This Product

• Purpose-Built Fit: Specifically designed for the Magene EXAR Ultra DB405 wheelset.

• Lightweight Construction: Carbon fiber construction keeps individual spoke weight very low.

• Performance Focus: Helps preserve the stiffness, responsiveness, and aerodynamic characteristics of the original wheelset.

• Multiple Configurations: Available for different front and rear wheel positions.

• Reliable Replacement: A suitable option for restoring a DB405 wheel after spoke damage or replacement needs.

In the Box

• 1 × Magene EXAR Carbon Spoke for Ultra DB405
